Safe Edge Corten Steel External Corner With Safety Fold

$9.50 AUD
$9.50 AUD
Sold Out

Tax included.

Size: 100mm

🚚 Free delivery over $150 (selected Melbourne Metro areas)

Delivered within 5 business days

In-stock items only. Special orders may require additional lead times.

Check delivery eligibility & zones

Outside these areas? Contact us for a freight quote

Safe Edge Corten Steel External Corner with Safety Fold

Continue Chippy’s Safe Edge system neatly around a 90-degree external corner without cutting or re-forming the folded top. Choose the external corner where the smooth finished face of the Safe Edge wraps around the outside corner of a garden bed, planter or landscape feature. It connects to the straight edging from behind using two matching joining plates.

  • Purpose-made for 90-degree external corners

  • Maintains the continuous folded top

  • Formed to 90 degrees, with minor adjustment possible on site

  • 150 mm leg on each side

  • Available in 100, 150 and 280 mm heights

  • Pre-drilled joining holes on both legs

  • No supporting peg required at the corner

  • Manufactured in Melbourne

The Safe Edge external corner creates a clean 90-degree change of direction around a projecting corner while carrying the folded top continuously through the turn.

It removes the need to cut through the safety fold and attempt to recreate the finished top on site. That gives DIY customers and landscapers a cleaner, more predictable connection and keeps the visible corner consistent with the rest of the Safe Edge run.

The folded top and formed corner add rigidity at the change of direction, so the corner does not require a supporting peg. The angle can also be adjusted slightly on site where the garden layout is not perfectly square.

This accessory is designed specifically for Chippy’s Safe Edge system.

100 mm external corner

  • Matches 100 mm Safe Edge
  • 90-degree external corner
  • 150 mm legs

150 mm external corner

  • Matches 150 mm Safe Edge
  • 90-degree external corner
  • 150 mm legs

280 mm external corner

  • Matches 280 mm Safe Edge
  • 90-degree external corner
  • 150 mm legs

All sizes allow minor angle adjustment during installation.


Choose the external corner where the smooth finished face of the Safe Edge wraps around the outside corner of a garden bed, planter or landscape feature. For a recessed or inside corner, choose the Safe Edge internal corner.

The external corner forms the visible change of direction.

Matching Safe Edge joining plates sit behind the two connections between the corner and the straight edging lengths.

The corner legs and Safe Edge lengths have pre-drilled joining holes. The joining plates are intentionally supplied without holes, allowing their fixing positions to be set through the pre-drilled edging and adjusted for small installation tolerances. This helps the installer align the folded tops and maintain a clean, continuous top line.

For one external corner, allow:

  • One matching external corner
  • Two matching joining plates—one for each side
  • A suitable roofing-screw or pop-rivet fixing packet, purchased separately

The corner does not need a peg for additional support. Its formed shape provides rigidity, and the first peg along each straight length should generally be positioned approximately 500 mm from the corner.

  1. Confirm that the edging is wrapping around a projecting external corner—not turning into a recessed internal corner—and select the matching height.
  2. Set the external corner in its final position and check the 90-degree alignment. The angle can be adjusted slightly on site if required.
  3. Bring each straight Safe Edge length to the corner.
  4. Place a matching joining plate behind each connection and align the folded tops.
  5. Clamp the joining plate firmly in position. Use a small G-clamp from underneath, or a larger G-clamp fitted over the folded top.
  6. Use the pre-drilled holes in the corner and edging to set the fixing positions through the un-drilled joining plates.
  7. Use a normal drill at slow speed with suitable roofing screws, or pre-drill the joining plate for suitable pop rivets. Roofing-screw and pop-rivet packets are sold separately.
  8. Repeat the clamping and fixing process on the other side of the corner.
  9. Keep fixings in the lower third so they can be concealed where practical.
  10. Do not place a peg at either corner connection. Begin the supporting pegs along the straight edging approximately 500 mm from the corner, then check the finished line before backfilling.

The corner is supplied as raw grey weathering steel and will change colour as it is exposed to repeated moisture and drying. The corner and adjoining Safe Edge lengths may begin at slightly different stages of weathering, but their finishes will continue to develop outdoors.

Initial colour may appear within weeks; a fuller patina can take a couple of months. Timing varies with weather, season and orientation.

Rust-coloured runoff can stain concrete, paving, stone and other porous surfaces. Plan drainage before installation. The product does not need to be painted to develop its natural finish.
